Description

Video & Audio

  • Image Sensor : 1/2.7″ CMOS Sensors
  • Video Resolution : Default: 4608X1728 (8.0 megapixels) at 20 fps
  • Lens : f = 3.2 mm fixed, F = 2.0
  • Video Format : H.265
  • Field of View : Horizontal: 180° /  Vertical: 60°
  • Day & Night : Auto-switching with IR cut filter
  • Infrared Night Vision : 30 meters (LED: 6pcs/20mil/850nm)
  • Color Night Vision : Spotlight: 8pcs/5W/6500K/560 Lumens
  • Audio : Two-way audio

Power

  • DC Power : DC 12.0V⎓2A, <15W

Interface

  • Power : DC power port
  • System : Reset button
  • Ethernet : One 10M/100Mbps; RJ45
  • Storage : microSD card slot (Max. 256GB)
  • Audio : Built-in microphone and speaker.

Software Features

  • Frame Rate :  Mainstream: 4fps – 20fps (default: 20fps) /  Substream: 4fps – 20fps (default: 10fps)
  • Code Rate :  Mainstream: 3072Kbps -10240Kbps(default: 5120Kbps)  Substream: 256Kbps – 2048Kbps(default: 1024Kbps)
  • Browser Supported : Edge, Chrome, Firefox, Safari
  • OS Supported : PC: Windows, Mac OS; Smartphone: iOS, Android
  • Smart Alarm : Motion detection; person detection; vehicle detection; pet detection
  • Record Mode : Motion-triggered recording (default); scheduled recording; 24/7 recording
  • Protocols & Standards : HTTPS, SSL, TCP/IP, UDP, HTTP, IPv4, UPnP, RTSP, RTMP, ONVIF, SMTP, NTP, DHCP, DNS, DDNS, FTP, P2P
  • Maximal User Access : 20 Users (1 admin account & 19 user accounts); Support up to 12 simultaneous video streams (10 substreams & 2 mainstreams)
  • Works with : Google Assistant

Wi-Fi

  • Wireless Standard : IEEE 802.11a/b/g/n
  • Operating Frequency : 2.4GHz/5GHz
  • Wireless Security : WPA-PSK/WPA2-PSK

Working Environment

  • Temperature : Operating temperature: -10°C~+55°C (14°F~131°F)
  • Humidity : Operating humidity: 10% ~ 90%
  • Waterproof : IP66

Size & Weight

  • Dimension : 195x103x56 mm
  • Weight : 700g
