Dahua AC Standalone Fingerprint with Keypad and LCD display ASI2212H-W (P2P Registration)

Description

System

Main Processor : High-performance embedded processor
Network Protocol : IPv4; TCP; UDP; P2P
Basic

Display Screen : 2.4″ LCD
Screen Type : LCD
Resolution : 240 (H) × 320 (V)
Voice Prompt : Yes
Buzzer : Yes
Casing : PC + ABS
Function

Unlock Mode : Card/Remote/Password/Fingerprint unlock and unlock through their combinations
Card Type : IC or ID card
Period List : 128
Holiday Period : 128
Network Update : Yes
First User Unlock : Yes
Remote Verification : Yes
Restricted List/Trusted List : Yes
Wi-Fi : Yes
Peripheral Card Reader : 1 × RS-485 card reader / 1 × Wiegand card reader
Multi-user Authentication : Yes
Multi-factor Authentication : Yes
Web Configuration : Yes
Auto Registration : Yes
Performance

Card Reading Distance : 0-5 cm
Fingerprint Sensor Type : Capacitive fingerprint scanner
Fingerprint Comparison Time : 1 s
User

User (Card) Type : General user, VIP user, patrol user, guest user, blocklist user and others
Capacity

User Capacity : 30,000 users
Fingerprint Capacity : 3,000
Card Capacity : 30,000
Password Capacity : 30,000
Record Capacity : 150,000 unlock records
Port

RS-485 : 1
RS-232 : 1
Wiegand : 1-ch input/output
USB : 1 × USB2.0 port
Network Port : 1 × RJ-45, 100 Mbps
Alarm Input : 2 (digital quantity)
Alarm Output : 1 (relay)
Alarm Linkage : Yes
Doorbell : 1
Exit Button : 1
Door Status Detection : 1
Lock Control : 1
Alarm

Anti-pass Back : Yes
Tamper Alarm : Yes
Duress Alarm : Yes
Door Sensor Timeout : Yes
Intrusion : Yes
Illegal Card Exceeding Threshold : Yes
Duress Fingerprint : Yes
General

Power Adapter : Optional
Power Supply : 12 V DC, 1 A
Protection : IP65 (silicone sealant is needed, see the quick start guide)
Power Consumption : ≤ 12 W
Product Dimensions : 183 mm × 80 mm × 25.5 mm
Packaging Dimensions : 248 mm × 143 mm × 66 mm
Operating Temperature : –30 °C to +65 °C (–22 °F to +149 °F)
Operating Humidity : 10%–95% (RH), no condensing
Operating Environment : Indoor; outdoor
Net Weight : 262 g
Gross Weight : 462 g
Accessory : Bracket (included)
Installation : Surface mount
Certifications : CE; FCC
