AJAX Wall Switch

SKU: WallSwitch

69.00

Description

  • The radio channel controller allows to control domestic appliances remotely. It is used to switch on/off irons, garage gates, water heaters and heat-insulated floors
  • The device controls the electric power supply by means of relay, which closes and opens the power supply network
  • Boost the potential of your security system with scenarios to actively resist the threats it detects and automate your routines. Set up a Night mode activation on schedule; turn off all the office lights automatically by arming the system; program the outdoor lights to spotlight trespassers when they trigger an outdoor motion detector; or install a sustainable anti-flood system. The system continues to execute scenarios even if the connection with Ajax Cloud is lost
  • Actuating element :  Electromagnetic relay
  • The service life of the relay :  200,000 switching-ons
  • Supply voltage : 110 – 230 V AC ± 10% 50/60 Hz
  • Voltage protection For 230 V mains : max 253 V, min 184 V
  • Maximum load current :  13 ?
  • Maximum current protection : Yes, 13 A
  • Power output (resistance load 230 V) : Up to 3 kW
  • Electricity meter function :  Yes
  • Power consumption parameters control Yes: current, voltage,
  • consumed power
  • The power consumption of the device in the standby mode :  Less than 1 W⋅h
  • Frequency band : 868.0 – 868.6 MHz or 868.7 – 869.2 MHz depending on the region of sale
  • Compatibility Operates only :  with Hub, Hub Plus, Hub 2 and ReX
  • Maximum RF output power :  Up to 25 mW
  • Modulation : GFSK
  • Radio signal range : Up to 1,000 m (any obstacles absent)
  • Shell protection rating : IP20
  • Operating temperature range :  From 0°? to +64°?
  • Maximum temperature protection : Yes, 65°C
  • Operating humidity : Up to 75%
  • Overall dimensions : 39 ? 33 ? 18 mm
  • Weight : 30 g

Additional information

Installation

NO +€0, YES + €80
